Introduction

Water is a fundamental necessity in human life, and ensuring its availability is crucial in various settings, including households, offices, public facilities, and industries. The role of water reservoirs becomes vital to guarantee water availability at any time. To maintain water availability automatically, a water level measurement mechanism is necessary. One solution is to use a water level measuring sensor connected to a pump to fill the water reservoir. This article discusses the design of a water volume measuring device in containers using HC-SR04 ultrasonic sensors based on Arduino.

Background and Importance of Water Level Measurement

Water level measurement is a critical aspect of water management, especially in areas where water scarcity is a significant concern. Accurate measurement of water levels enables users to monitor water availability, regulate consumption, and take necessary actions when water supply begins to decrease. This not only saves energy but also prevents overfilling, which can cause leakage or damage to the shelter system.

Main Components in Designing

The design of the water volume measuring device consists of several key components:

1. Ultrasonic Sensor HC-SR04

The HC-SR04 ultrasonic sensor is an efficient measuring element that uses ultrasonic waves to measure distance. In this application, the sensor will be used to measure the height of the water in the container. The sensor works by emitting sound waves and measuring the time required for waves to return after bouncing from the surface of the water. By using the time formula and sound speed, the height of the water surface can be calculated accurately.

2. Arduino Microcontroller

The Arduino microcontroller serves as the brain of the system, processing data from the sensor and controlling the water pump. Arduino has various ports that facilitate connections with sensors and other components. The microcontroller will process the data obtained from the sensor and display the water level information on the LCD.

3. LCD 16x2

The LCD 16x2 screen is used to display water level information and pump status. This information will help users monitor the state of the water container directly. The LCD will display the current water level, the threshold level, and the pump status.

4. Water Pump

The water pump will be turned on or turned off based on measurable water levels. The microcontroller will control the pump operation with the right automation. When the water level drops below the specified threshold, the pump will turn on to fill the container. When the container is almost full, the pump will turn off to prevent overfilling.

Additional Analysis and Explanation

With this system, users no longer need to worry about the availability of water in a container. The system will automatically fill water when the water level drops below the specified threshold and turn off the pump when the container is almost full. This not only saves energy but also prevents overfilling, which can cause leakage or damage to the shelter system.

This measurement system also provides more benefits in terms of efficiency and cost savings. With continuous monitoring, users can more easily regulate water consumption and take the necessary actions when water supply begins to decrease. The system can be used in various applications, including households and industries, to improve the efficiency of water use and provide practical solutions to water management problems.

Testing and Results

In testing, this tool shows satisfying results with the ability to show the water level on the LCD display according to the actual conditions in the container. This gives confidence that the system can be relied upon and used in various applications. The system has been tested in different scenarios, including varying water levels and pump operations, and has shown accurate results.

Conclusion

The design of the water volume measuring device in containers using HC-SR04 ultrasonic sensors based on Arduino provides a practical solution to water management problems. The system is efficient, cost-effective, and easy to use, making it suitable for various applications, including households and industries. With the right technology, we can ensure the availability of water that is always adequate for everyday life.

Future Work

Future work can focus on improving the accuracy of the system, increasing the range of the ultrasonic sensor, and integrating the system with other sensors and devices to provide a more comprehensive water management solution. Additionally, the system can be modified to accommodate different types of containers and water sources.
