Introduction

When two parallel wires carry electric currents, they interact with each other through the magnetic field generated by the currents. In this scenario, we have two parallel wires where the magnitude of the left current is $2I_o$ and that of the right current is $I_o$ . We need to determine the magnetic field at point A, which is midway between the wires, and point B, which is an equal distance on the other side of the wires.

The Magnetic Field

The magnetic field generated by a current-carrying wire is given by the Biot-Savart law. The law states that the magnetic field at a point due to a current element is proportional to the current, the length of the element, and the sine of the angle between the element and the point. The direction of the magnetic field is given by the right-hand rule.

Magnetic Field at Point A

Point A is midway between the wires, so the distance from each wire to point A is equal. Let's denote this distance as $r$ . The magnetic field at point A due to the left wire is given by:

B_{A,left} = \frac{\mu_0}{4\pi} \cdot \frac{2I_o}{r}

The magnetic field at point A due to the right wire is given by:

B_{A,right} = \frac{\mu_0}{4\pi} \cdot \frac{I_o}{r}

Since the wires are parallel, the magnetic fields at point A due to each wire are in the same direction. Therefore, the total magnetic field at point A is the sum of the magnetic fields due to each wire:

B_A = B_{A,left} + B_{A,right} = \frac{\mu_0}{4\pi} \cdot \frac{3I_o}{r}

Magnetic Field at Point B

Point B is an equal distance on the other side of the wires, so the distance from each wire to point B is also equal. Let's denote this distance as $r$ . The magnetic field at point B due to the left wire is given by:

B_{B,left} = \frac{\mu_0}{4\pi} \cdot \frac{2I_o}{r}

The magnetic field at point B due to the right wire is given by:

B_{B,right} = \frac{\mu_0}{4\pi} \cdot \frac{I_o}{r}

Since the wires are parallel, the magnetic fields at point B due to each wire are in the same direction. Therefore, the total magnetic field at point B is the sum of the magnetic fields due to each wire:

B_B = B_{B,left} + B_{B,right} = \frac{\mu_0}{4\pi} \cdot \frac{3I_o}{r}

Comparison of Magnetic Fields

We can see that the magnetic fields at point A and point B are equal. This is because the distance from each wire to point A and point B is the same, and the magnetic fields due to each wire are in the same direction.

Conclusion

In conclusion, the magnetic field at point A and point B due to two parallel wires carrying currents of $2I_o$ and $I_o$ is given by:

B_A = B_B = \frac{\mu_0}{4\pi} \cdot \frac{3I_o}{r}

The magnetic fields at point A and point B are equal due to the symmetry of the situation.
