Introduction

When working with robots, especially those with end-effectors, it's essential to understand the best practices for changing the end-effector. This is particularly crucial when using a robot like the FR3, which has a camera mount attached to the flange and hand. In this article, we'll explore the best practices for updating the TCP (Tool Center Point) to reflect the offset caused by the camera mount.

Understanding the Problem

When a camera mount is attached to the flange and hand of the FR3 robot, it creates an offset of a few millimeters. This offset affects both the default TCP and the pose of the end-effector. To accurately control the end-effector and read its state, it's essential to update the TCP to reflect this offset.

Current Approach

The current approach involves updating the URDF (Unified Robot Description Format) by modifying the joint8 in the kinematics.yaml file. This increases the z-value by a few millimeters to reflect the offset. Additionally, the /service_server/set_tcp_frame service is used to set the TCP frame to reflect the same offset.

Code Modifications

The code modifications involve updating the Cartesian pose example controller, which is based on the franka_ros2 repository. The modifications are minimal, and the code is available on GitHub.

Best Practices for Changing the End-Effector

Update the URDF: The first step is to update the URDF by modifying the joint8 in the kinematics.yaml file. This ensures that the robot's kinematics are accurately reflected.
Use the /service_server/set_tcp_frame service: This service is used to set the TCP frame to reflect the offset caused by the camera mount.
Verify the offset: It's essential to verify that the offset is correctly reflected in both the URDF and the TCP frame.
Consider using a more robust method: While the current approach works, it's essential to consider using a more robust method, such as using a calibration process or a more advanced kinematics model.

Additional Considerations

Stiffness frame: The /service_server/set_stiffness_frame service is not directly related to updating the TCP frame. However, it's essential to consider the stiffness of the end-effector when making changes to the TCP frame.
Future-proofing: When making changes to the end-effector, it's essential to consider future-proofing. This includes ensuring that the changes are compatible with other grippers or end-effectors that may be used in the future.

Conclusion

Changing the end-effector of a robot like the FR3 requires a comprehensive understanding of the best practices involved. By following the steps outlined in this article, you can ensure that the TCP frame is accurately updated to reflect the offset caused by the camera mount. Additionally, by considering the additional factors outlined in this article, you can ensure that your changes are robust and future-proof.

Future Work

Calibration process: Developing a calibration process to accurately determine the offset caused by the camera mount.
Advanced kinematics model: Developing a more advanced kinematics model to accurately reflect the robot's kinematics.
Robust method for updating the TCP frame: Developing a more robust method for updating the TCP frame, such as using a more advanced algorithm or a more accurate kinematics model.

Code Snippets

Cartesian pose example controller: The code for the Cartesian pose example controller is available on GitHub.
Kinematics.yaml file: The kinematics.yaml file is available on GitHub.
URDF update: The code for updating the URDF is available on GitHub.

References

Franka ROS2 repository: The franka_ros2 repository is available on GitHub.
URDF documentation: The URDF documentation is available on the ROS website.
TCP frame documentation: The TCP frame documentation is available on the ROS website.
