Comparison Analysis of Concentrated Winding and Toroidal Winding in the Three Phase Permanent Magnetic Axial Flux Magnet (AFPM) generator using an iron core on the stator

Introduction

The world is facing an increasing demand for efficient and environmentally friendly energy sources. Renewable energy has emerged as a primary alternative to meet this challenge. Among the various renewable energy sources, the Axial Flux Permanent Magnet (AFPM) generator has gained significant attention due to its ability to harness energy from wind and water. The AFPM generator is designed with a stator without a core using concentrated winding configuration. However, this study aims to compare two types of stator configurations that use iron core, namely concentrated winding and toroidal winding.

Background

The growth of industry and increasing energy demands have led to a pressing need for efficient and sustainable energy sources. Renewable energy has become a crucial component in addressing this challenge. The AFPM generator is an attractive option for harnessing renewable energy due to its ability to utilize energy from wind and water. The generator analyzed in this study has identical rotor and stator specifications, designed to produce a 110-volt voltage with a frequency of 50 Hz and a power of about 100 watts.

Experimental Setup and Results

The three-phase AFPM generator was tested using both concentrated winding and toroidal winding configurations. The results show that for the Concentrated Winding configuration, the testing voltage without a load reaches around 106.5 volts, whereas when the load produces a voltage of around 45.6 volts with a power of around 87.15 watts. This generator efficiency was recorded at 72.61%. On the other hand, the Toroidal Winding configuration recorded a voltage without a load of around 110.6 volts and when it was loaded around 42.4 volts, with a power generated of 77.16 watts and an efficiency of 70.51%.

Comparison of Concentrated Winding and Toroidal Winding

From the results of these tests, it can be concluded that the Concentrated Winding configuration is superior compared to Toroidal Winding in terms of efficiency and output power. However, the fundamental difference between the two configurations lies in the method of generating magnetic fields and magnetic flux arrangements.

In-Depth Analysis

Concentrated winding, with a simpler design, allows electric current to flow more effectively, produce larger magnetic flux per unit area. This means that for the same size and weight, generators with concentrated winding configuration can produce higher power. Meanwhile, Toroidal Winding, although it has an advantage in the distribution of magnetic flux which is more evenly distributed and can reduce Eddy Current losses, resulting in slightly lower efficiency. The composition of the iron core in Toroidal Winding is indeed able to stabilize the magnetic field, but the complexity of the design and the high number of turns makes the production process more complicated and increase costs.

Practical Perspective

From a practical perspective, the selection between concentrated winding and toroidal winding will be very dependent on specific applications. If the main focus is efficiency and output power, then concentrated winding is clearly a better choice. However, if the application requires a more equitable distribution of flux and more stable operating characteristics, toroidal winding can be considered even with lower efficiency.

Conclusion

In the context of the development of renewable energy technology, a deep understanding of various electricity generation configurations like this is very important. The results of this study can be a reference for engineers and researchers in designing generators that are more efficient and effective to utilize renewable resources, helping to meet world energy needs that continue to increase in a more sustainable way.

Recommendations

Based on the results of this study, the following recommendations can be made:

Concentrated winding is a better choice for applications that require high efficiency and output power.
Toroidal winding can be considered for applications that require a more equitable distribution of flux and more stable operating characteristics.
Further research is needed to optimize the design of toroidal winding configurations to improve efficiency and reduce production costs.

Future Work

Future work can focus on the following areas:

Optimizing the design of toroidal winding configurations to improve efficiency and reduce production costs.
Investigating the effects of different materials and configurations on the performance of AFPM generators.
Developing new designs and configurations for AFPM generators that can improve efficiency and reduce costs.

References

[List of references cited in the study]

Appendix

[Appendix containing additional information and data]
