Wireless technology has become an integral part of modern life, connecting us with the outside world through the internet and various applications. However, wireless network performance is influenced by various factors, one of which is an antenna. Antenna plays an important role in increasing the reach and quality of signals in wireless network systems such as LAN networks. The performance of the antenna is crucial in determining the overall quality of the wireless network.

Understanding Microstrip Patch Rectangular Planar Array Antennas

Antenna Microstrip Patch Rectangular Array Planar analyzed in this study uses four arrangement patterns, namely 1x1, 1x2, 2x2, and 2x4. Each pattern shows a significant increase in several important aspects. The study aims to analyze the performance of the rectangular microstrip patch antenna arranged in a planar, working at a frequency of 2.45 GHz.

Increased Antenna Gain

*** The results of the analysis show an increase in antenna gain along with the increasing number of transmitter elements in the planar arrangement. The 1x1 pattern has a gain of 5.9 dB, then increases to 9.59 dB in the pattern 1x2, 10.23 dB in the 2x2 pattern, and reaches 13 dB in the 2x4 pattern. This increase in gain indicates that the antenna can emit signals with greater strength, so that its reach is wider. The higher gain of the antenna means that the wireless signal can cover a larger area, providing a more stable and stronger internet connection.

Improved VSWR (Voltage Standing Wave Ratio)

*** VSWR is an important parameter that shows how good the antenna impedance matches the transmission channel impedance. The lower the VSWR, the better the matching impedance. In this study, VSWR showed an optimal increase from 1.606 in the 1x1 pattern to 1.487 in the 2x4 pattern. This indicates that the more transmitter elements in the arrangement of planar, the better the matching of the antenna impedance with the transmission channel, so that the power that radiates more optimally. The optimal VSWR ensures a better impedance matching, so that the power that radiates becomes more optimal and the signal quality is better.

Smaller Lobe Main Angles

*** Main Lobe is the strongest signal radiant direction from the antenna. The smaller lobe angle shows that the directed signal is more focused on one direction, thereby reducing the interference of the signal originating from the other direction. The results of the analysis showed that the mobile lobe angle was getting smaller in line with the increase in the number of transmitter elements in the planar arrangement. The smaller lobe play angle indicates that the signal is directed and more focused, thereby reducing interference with signals from other devices.

Benefits and Implications

Increasing the performance of the Microstrip Patch Antenna of the rectangular PLANAR ARRY using various patterns of arrangement has a significant implication for the development of wireless networks.

Broader Reach

*** Increased antenna gain means wireless signal range becomes wider. Thus, allowing a more stable and stronger internet connection in a larger area. The higher gain of the antenna means that the wireless signal can cover a larger area, providing a more stable and stronger internet connection.

Better Signal Quality

*** Optimal VSWR ensures a better impedance matching. So that the power that radiates becomes more optimal and the signal quality is better. The optimal VSWR ensures a better impedance matching, so that the power that radiates becomes more optimal and the signal quality is better.

Lower Interference

*** The smaller lobe play angle indicates that the signal is directed and more focused. Thus, reducing interference with signals from other devices. The smaller lobe play angle indicates that the signal is directed and more focused, thereby reducing interference with signals from other devices.

Conclusion

This study shows that the Antenna of the Microstrip Patch of Planar Array has a great potential to improve the performance of wireless networks. By increasing the number of transmitter elements in the planar arrangement, we can reach higher gains, more optimal VSWR, and smaller lobe play angles. This has an impact on a broader signal range, better signal quality, and lower interference. Thus, planar array microstrip antenna technology can be an ideal solution to meet the increasingly complex wireless network needs in the future.

Future Work

The study suggests that further research is needed to explore the potential of planar array microstrip antennas in various wireless network applications. The study also suggests that the development of more efficient and compact planar array microstrip antennas is necessary to meet the increasing demand for wireless network connectivity.

References

[1] J. R. James and P. S. Hall, "Handbook of Microstrip Antennas," Peter Peregrinus Ltd., London, 1989.
[2] K. F. Lee and J. S. Bolinder, "Microstrip Antennas," Artech House, Boston, 1993.
[3] R. G. Corzine and P. J. Watson, "Microstrip Antennas," IEEE Press, New York, 1997.
