Introduction to High Beams and Strut-And-Tie Model

High beams are structural elements that play a crucial role in reinforced concrete construction, such as shear walls, couple beams, pile caps, and head pillars over the bridge. These elements are designed to withstand significant shear loads, and their voltage and strain behavior tends to be nonlinear. The Strut-and-Tie Model (STM) method is a common choice for analysis and design of high beams due to its ability to provide a better understanding of the flow of voltage and the distribution of force in the concrete structure.

Understanding the Importance of SNI 2847-2019 in High Beam Analysis

SNI 2847-2019 is a standard that provides guidelines for the design and analysis of high beams. The standard outlines the dimensions and blocks of beams that are designed according to these standards, and then analyzed using STM based on SNI 2847-2019. The selection of the frame model of the stem according to SNI is based on the voltage flow obtained through the non-linear analysis software of Lusas14. The CAST (Computer Aided Strut and Tie) program is also used to compare the results of the analysis of various STM methods.

High Beam Analysis: The Combination of SNI 2847-2019 and Recognized STM Models

This study focuses on high beam analysis based on SNI 2847-2019. The dimensions and blocks of beams are designed according to these standards, then analyzed using STM based on SNI 2847-2019. In comparison, the five recognized STM models are also used to assess the effectiveness of the design results based on SNI. The selection of the frame model of the stem according to SNI is based on the voltage flow obtained through the non-linear analysis software of Lusas14. The CAST program is also used to compare the results of the analysis of various STM methods.

The Role of STM in High Beam Analysis

The STM method is a powerful tool for analyzing high beams. It allows a better understanding of the flow of voltage and the distribution of force in the concrete structure. The STM method is based on the concept of struts and ties, which are used to represent the flow of voltage and the distribution of force in the concrete structure. The STM method is widely used in the design and analysis of high beams due to its ability to provide accurate and reliable results.

Uncover SNI 2847-2019 Efficiency through STM and Cast Analysis

The results of the analysis showed that the design of high beams based on SNI 2847-2019 was quite effective. The force ratio value obtained in each STM method, including cast analysis, shows a number below one. That is, the force capacity of each truss element is greater than the stem force acting on each element, shows a safe structure.

The results of STM analysis showed the average force ratio for model-1 to model-6 was 0.846; 0.756; 0.746; 0.668; 0.642; and 0.744. Meanwhile, the cast analysis produced an average force ratio of 0.869; 0.803; 0.845; 0.695; 0.768; and 0.781.

Conclusion: SNI Validation and Cast Advantages

Based on the results of the analysis, it can be concluded that there is no significant difference between the results of STM and Cast analysis. This shows that SNI 2847-2019, supported by the STM method, is able to provide safe and efficient design results for high beams.

Program Cast, with its ability to analyze and visualize the STM model, become an effective tool in validating design results and assisting in the design process. The existence of cast makes it easy for engineers to simulate and optimize design, produces optimal and efficient structures.

Benefits of Articles:

This article provides insight into high beam analysis with the STM method and SNI validation 2847-2019. This information is useful for structural engineers, students, and professionals in the field of reinforced concrete construction. This article also highlights the role of Cast as a software that helps in the design and analysis process, improve design efficiency and accuracy.

Future Research Directions:

This study provides a comprehensive analysis of high beam analysis based on SNI 2847-2019 and recognized STM models. However, there are still many areas that require further research. Some of the future research directions include:

Development of new STM models: The development of new STM models that can provide more accurate and reliable results is an area that requires further research.
Improvement of Cast software: The improvement of Cast software to make it more user-friendly and efficient is an area that requires further research.
Application of STM in other fields: The application of STM in other fields such as bridge design and building design is an area that requires further research.

Conclusion:

In conclusion, this study provides a comprehensive analysis of high beam analysis based on SNI 2847-2019 and recognized STM models. The results of the analysis showed that the design of high beams based on SNI 2847-2019 was quite effective. The force ratio value obtained in each STM method, including cast analysis, shows a number below one. That is, the force capacity of each truss element is greater than the stem force acting on each element, shows a safe structure.
